Solenoid coil 24 V 25/221263 JCB, aftermarket

25/221263

Brand
JF Parts
Article
25/221263
Machine system
Electrics
Part type
Solenoid coil
Machine brand
JCB
Manufacturing type
Aftermarket
All the features

In stock

0.00 ₺

We do not publish prices: they depend on exchange rates and change often. Click «Request price» and we will quote the current price on the day you ask.

Check the exact specifications and compatibility with your machine with our managers.

We are available Monday to Saturday, 9:00 – 18:00; closed on Sunday.

Free delivery to the carrier of your choice, or collect your order in Istanbul.

Could not find the part you need? Write to us and we will help you find an alternative or order it from the manufacturer.

Message on WhatsApp Message on Telegram Call us: +90 531 224 49 66

For the JCB machines: solenoid coil 24 V 25/221263, an aftermarket part. The card also lists 717/20309.

According to sources, the numbers 25/221263 and 717/20309 refer to the same solenoid coil, used on JCB backhoe loaders, wheeled loaders and JS excavators. The body of the coil in the photo is marked DC 24 V / 14 W. When replacing a coil, its voltage must match the machine's system: a 24 V coil pulls weakly on 12 V, and a 12 V coil soon burns out on 24 V. The coil connector must match its mate on the harness. A plastic-bodied coil can crack if its fixing nut is overtightened. The coil slides onto the valve cartridge tube and is held by the nut on top, so it can be changed without opening the hydraulics. Never remove a live coil from its cartridge, since without the cartridge it soon overheats and burns out. When the coil burns out the connected function stops; first measure the voltage at the connector and the coil resistance.

Specifications

Part number	25/221263
Cross / alternative numbers	717/20309
Production type	Aftermarket
Part type	Solenoid coil
System / group	Electrics
Machine make	JCB

Compatibility

Other parts are in Relays.

Fitting

After fitting, secure the harness with ties so it does not touch moving parts or hot surfaces, since a chafed wire loses its insulation and causes a short circuit.

Specifications

Machine system
Electrics
Part type
Solenoid coil
Machine brand
JCB
Manufacturing type
Aftermarket

Questions: 0

No questions about this product.
