Fuel fine filter 32/925932 JCB, genuine

Fuel fine filter 32/925932 is a genuine JCB part for the JCB machines. This element is the fine (main) fuel filter fitted after the pre-filter.

After changing the fuel filter it is important to bleed the air from the system, since air left in the line stops the engine starting or makes it stall after starting. Open the bleed screw on the filter head or pump and operate the hand primer until no more bubbles appear. In winter, waxing fuel can block the filter quickly, so winter-grade fuel is used in cold climates and the filter changed more often if needed.

Specifications

Compatibility

According to sources, 32/925932 and 32/926138 are numbers of the same fuel filter; the product cards also give 32/925451, 332/Z0589 and 32/925919. Fit is confirmed by the machine serial number. The catalogue also has the aftermarket version of this part. Other parts are in Genuine JCB filters.

Fitting

Before the change, stop the engine and clean around the filter. Remove the old filter and wipe the seal face of the filter head. Lightly lubricate the new filter's seal with clean fuel, screw the filter on by hand and, once the seal touches, tighten it by the amount the maker specifies; overtightening with a wrench crushes the seal and makes removal hard. Then bleed the fuel system with the hand primer or the method in the manual, start the engine and check for leaks. Clean hands and tools matter when changing a fuel filter, since dirt on the filter head can reach the clean side of the new filter. Do not overtighten the bleed screw on the filter head.
