Bucket tooth retainer kit 54204202 MST, aftermarket

Bucket tooth retainer kit 54204202 is an aftermarket part for the MST backhoe loaders. According to the product card, this part is a bucket tooth retainer kit.

The retaining pin secures the bucket tooth (tip) to the tooth adaptor. It usually works together with a rubber or spring retainer and stops the tooth coming off while digging. A worn or bent pin, or one with a failed retainer, lets the tooth come off and be lost; the adaptor then works directly in the material and wears fast, and a lost tooth that gets into a crusher can cause serious damage. The pin is chosen by tooth system, as different systems of the same tooth size use different pins. The bucket teeth and their pins are inspected at the start of every shift. When a new pin is fitted, the rubber lock or washer is replaced too, as the old locking element no longer holds the pin firmly.

Specifications

Compatibility

According to the product card, the part number is 54204202. Fit is confirmed by the part number and the adaptor or bucket model. Other parts are in Buckets.

Fitting

Drive the old pin out with a punch from the opposite side of the tooth. Fit the new tooth on the adaptor, place the retainer and hammer the pin in until fully seated. Wear eye protection, as sparks and fragments can fly when steel parts are struck.
