Hydraulic cylinder piston 595/10027, aftermarket, option 2

595/10027

Brand
Ceylan Hidrolik
Article
595/10027
Machine system
Hydraulic system
Part type
Cylinder piston
Machine brand
JCB
Manufacturing type
Aftermarket
Compatibility
JCB 3CX, 4CX
Machine series
3CX, 4CX, 5CX
All the features

In stock

0.00 ₺

We do not publish prices: they depend on exchange rates and change often. Click «Request price» and we will quote the current price on the day you ask.

Check the exact specifications and compatibility with your machine with our managers.

We are available Monday to Saturday, 9:00 – 18:00; closed on Sunday.

Free delivery to the carrier of your choice, or collect your order in Istanbul.

Could not find the part you need? Write to us and we will help you find an alternative or order it from the manufacturer.

Message on WhatsApp Message on Telegram Call us: +90 531 224 49 66

For the JCB 3CX and 4CX backhoe loaders: hydraulic cylinder piston 595/10027, 40x70x50 mm, an aftermarket part.

During a cylinder rebuild, the piston is checked for wear and scoring in its seal grooves, since new seals soon fail on a damaged piston. When the piston is replaced, the seal kit is renewed too and the barrel bore is inspected for scoring. The piston-to-rod joint is one of the most heavily loaded points in the cylinder, so its fixing is tightened to the specified torque. This piston is the second aftermarket option for the same number, with the same grooves and the same seal kit. It is supplied new, and its seal grooves must be protected from knocks in transit. Check the piston and seal kit together, renewing worn seals with the new piston. The piston is heavy.

Specifications

Part number	595/10027
Production type	Aftermarket
Part type	Cylinder piston
System / group	Hydraulic system
Machine make	JCB
Series / model	3CX, 4CX, 5CX
Size	40x70x50 mm

Compatibility

The catalogue also has the aftermarket version of this part. Other parts are in JCB hydraulic cylinders.

Fitting

Lay the seals and wear rings in their grooves without twisting, fit the piston to the rod and tighten its fixing to the specified torque. Oil the rod and piston with clean hydraulic oil and ease them into the barrel without dragging the seals over threads or edges.

Specifications

Machine system
Hydraulic system
Part type
Cylinder piston
Machine brand
JCB
Manufacturing type
Aftermarket
Compatibility
JCB 3CX, 4CX
Machine series
3CX, 4CX, 5CX

Questions: 0

No questions about this product.
