Filter element 0240 R 010 ON HYDAC, genuine HYDAC

For the hydraulic systems: filter element 0240 R 010 ON, a genuine HYDAC product.

HYDAC 0240 R 010 ON is a filter element for return line filters. In the code, 0240 is the element size, R stands for a return line element and 010 for 10 micron filtration, while ON stands for Optimicron filter media. According to seller data, the element's standard collapse pressure is 20 bar. The photo shows the filter media printing on the element. A return element catches particles in the oil coming back from the system; a clogged element opens the bypass valve and unfiltered oil goes to the tank. Replace the element at the service interval or when the clogging indicator warns. The genuine HYDAC element is made to fit HYDAC filter housings exactly. When changing the element, clean the inside of the filter housing and check the housing seal. The element is chosen by the size and filtration rating in its code, since an element of a different rating changes the cleanliness level of the system. Metal particles on the removed element can point to a part that is wearing.

Specifications

Compatibility

Other parts are in Hydraulic valves.

Fitting

The amount of dirt and metal particles on the removed element says a lot about the condition of the system.
